Ships of the Imperial Navy: Data Sheet

An Official Publication of the Imperial Navy of Greater Zartania
December 1364 ed.

Ships of the Imperial Navy: Data Sheet, December 1364 ed.
Copyright 1364 by Royal Government Publishers, Ministry of Public Information & Customs, #113
  Royalty Blvd., Imperial City. All rights reserved. No part of this publication may be reproduced in
  any way without the express written permission of the Ministry of Public Information & Customs.
PRINTED IN THE KINGDOM OF EASTERN ZARTANIA

The following is a list of specifications for each class of warship currently operated by the Imperial Zartanian Navy.  All specifications have been given where possible.  Some data remains classified, however, due to reasons of national security.  All information has been cleared through the Ministry of Public Information & Customs.  This data sheet is compiled and published as a public service on behalf of the Imperial Navy and the Government of the Greater Zartanian Empire.
Khiem'Ra Class Fleet Carrier
Length:  1,062 feet
Beam:  126 feet 6 inches
Draft:  35 feet 8 inches
Displacement:  80,000 tons
Speed:  30+ knots  (Actual top speed CLASSIFIED.)
Engines:  four Dalmessik DNE-82A gas-turbines turning two shafts with 4-bladed screws
Hanger height:  25 feet
Flight deck angle:  10.30°
Aircraft:  90 airplanes (fixed- and swing-wing), and 8 helicopters
Anti-aircraft armament:  eight 5-inch guns; six missile launchers
Steam catapults:  four
Elevators:  four (three starboard side, one port side midships)
Crew:  5,000 (including approx. 2,800 aircrew)
Number in class:  two (three more projected)
Countries:  Zartania
Warbird Class Jump Carrier
Length:  1,005 feet
Beam:  121.5 feet
Draft:  32 feet
Displacement:  67,000 tons
Speed:  28+ knots (Actual top speed CLASSIFIED.)
Engines:  four Dalmessik DND-80G gas-turbines turning four shafts with 4-bladed screws
Hanger height:  23 feet
Aircraft:  40 airplanes (fixed-wing), and 8 helicopters
Anti-aircraft armament:  six 30mm machine guns; ten missile launchers
Steam catapults:  none
Elevators:  two (one starboard side, one port side midships)
Crew:  2,500 (including approx. 650 aircrew)
Number in class:  four (four more planned)
Countries:  Zartania
Stek Class Battleship
Length:  681 feet
Beam:  108 feet
Draft:  36 feet
Displacement:  57,216 tons
Speed:  30+ knots (Actual top speed CLASSIFIED.)
Engines:  four Dalmessik DNE-82A gas-turbines turning two shafts with 4-bladed screws
Main armament:  nine 16-inch 50-caliber guns mounted in three turrets of 3
Secondary armament:  twenty 5-inch guns; twenty 40mm machine guns; four guided missile launchers; four anti-aircraft missile launchers
Armor belt:  12 feet 2 inches
Deck armor:  4 inches
Turret armor:  17 inches
Crew:  2,753
Number in class:  three (two more planned)
Countries:  Zartania
Command Class Guided Missile Cruiser

Length:  581.6 ft
Beam:  62 ft
Draft:  29.5 ft
Displacement:  11,000 tons
Engines:  2 Dalmessik DNE-79D gas-turbines turning two shafts with 4-bladed screws
Horsepower:  60,000 hp
Top speed:  30 knots
Main armament:  two 5" guns; four guided missile and anti-aircract missile launchers
Torpedo tubes:  six firing standard 21" Type XIV-C torpedoes
Armor belt:  8"
Turret armor:  6"
Aircraft:  two helocopters
Crew:  442
Number in class:  six (four more planned)
Countries:  Zartania

Alfacron Class Heavy Cruiser

Length:  716.5 ft
Beam:  76.4 ft
Draft:  26 ft
Displacement:  21,500 tons
Engines:  4 Dalmessik DNE-80K gas-turbines turning two shafts with 4-bladed screws
Horsepower:  120,000 hp
Top speed:  33 knots
Range:  8,000 miles
Main armament:  nine 8" guns mounted in three turrets of 3
Secondary armament:  twelve 5" guns; twenty 3" guns; twelve 40mm machine guns
Armor belt:  8"
Turret armor:  6"
Aircraft:  4 helocopters
Crew:  1,860
Number in class:  five (three more planned)
Countries:  Zartania

Raider Class Light Cruiser

Length:  610 ft
Beam:  66.2 ft
Draft:  25 ft
Displacement:  14,600 tons
Engines:  4 Dalmessik DNE-68M gas-turbines turning two shafts with 4-bladed screws
Horsepower:  100,000 hp
Top speed:  31.5 knots
Range:  10,000 miles
Main armament:  six 6" guns mounted in three turrets of 2
Secondary armament:  six 5" guns; two guided missile launchers
Torpedo tubes:  one firing standard 21" Type XIV-C torpedoes
Armor belt:  5"
Turret armor:  5"
Crew:  1,200
Number in class:  seven (one more planned)
Countries:  Zartania

King Bruno Class Destroyer

Length:  563 ft
Beam:  55 ft
Draft:  29 ft
Displacement:  7,810 tons
Engines:  4 Dalmessik DNE-81P gas-turbines turning two shafts with 4-bladed screws
Horsepower:  80,000 hp
Top speed:  33 knots
Main armament:  four 5" guns
Secondary armament:  multiple 20mm and 40mm machine guns
Torpedo tubes:  six firing standard 21" Type XIV-C torpedoes
Crew:  296
Number in class:  twenty-five domestic version, two export version
Countries:  Zartania , Albion-Merité

"Heimer" Class Destroyer

Length:  513 ft
Beam:  56 ft
Draft:  26 ft
Displacement:  7,940 tons
Engines:  2 Essek DRL-3 geared steam turbines turning two shafts with 3-bladed screws
Horsepower:  102,000 hp
Top speed:  32.5 knots
Main armament:  four 4" guns; 2 SAM launchers; 2 SSM launchers
Secondary armament:  multiple 30mm machine guns; up to 40 mines/depth charges
Torpedo tubes:  four firing standard 21" Type XIV-C torpedoes
Crew:  368
Number in class:  two captured from Northern Gronk
Countries:  Western Zartania

"Thistland" Class Destroyer

Length:  463 ft
Beam:  49 ft
Draft:  19 ft
Displacement:  4,675 tons
Engines:  2 McDarin MGT-8 gas-turbines turning two shafts with 5-bladed screws
Horsepower:  54,450 hp
Top speed:  29 knots
Main armament:  one 4.5" gun mounted forward; one SAM launcher
Secondary armament:  multiple 20mm and 30mm machine guns
Torpedo tubes:  six firing standard 21" Type XIV-C torpedoes
Crew:  301
Number in class:  one captured from the MCZ during the invasion of Thistland
Countries:  Caledon

Seadragon Class Guided Missile Frigate

Length:  445 ft
Beam:  45 ft
Draft:  14.7 ft
Displacement:  3,605 tons
Engines:  2 Dalmessik DNE-59L gas-turbines turning one shaft with 4-bladed screw
Horsepower:  41,000 hp
Top speed:  29 knots
Main armament:  one 3" gun mounted forward
Secondary armament:  multiple 20mm and 40mm machine guns; two guided missile and anti-aircraft missile launchers
Torpedo tubes:  six firing standard 21" Type XIV-C torpedoes
Crew:  164
Number in class:  thirty domestic version; two export version
Countries:  Zartania , Albion-Merité

Attack Class Guided Missile Corvette

Length:  192 feet
Beam:  27 feet
Draft:  7 feet
Displacement:  430 tons
Engines:  three Dalmessik DNC-39P diesel engines turning one shaft with 4-bladed screw
Horsepower:  10,500 hp
Top speed:  30+ knots (Actual top speed is CLASSIFIED.)
Main armament:  one 57mm gun; eight SSM launchers with 40+ missiles
Secondary armament:  one 40mm machine gun; launchers for depth charges
Torpedo tubes:  four firing standard Type XIV-C torpedoes
Crew:  40
Number in class:  forty-three domestic version; sixteen export version
Countries:  Eastern Zartania , Albion-Merité , MLFLD , Western Zartania

"Cutter" Class Corvette

Length:  276 feet
Beam:  34 feet
Draft:  10 feet
Displacement:  1,320 tons
